4.007 – BB600 6 inch Composite Steel Deck Slab, Interior Bearing Wall (DWG)

The following detail contains our 6 inch straight block on a composite steel deck slab with a interior bearing wall

File Type: dwg
Categories: 04. Floor Connections & Transitions
Tags: 152mm, 6?, 6in, bearing wall, Composite, deck slab, dowels, dwg, gypsum, ICF, insulating concrete form, interior, six, standard, steel, Straight
