5.010 – BB600 6 inch Steel Frame Door Jamb, Direct Attached EIFS System Exterior (DWG)

The following detail contains our 6 inch straight block on steel frame door jamb attached to a EIFS system

File Type: dwg
Categories: 05. Window & Door Openings
Tags: 152mm, 6?, 6in, bb-600, bucking, caulk, Door, door frame, dwg, eifs system, framing, gypsym, Insulation, jamb, opening, six, steel door, Stucco
